Let’s get back to our Tour of Extensions that had to be kept aside for awhile with other concerns such as last chance PostgreSQL data recovery. Now that we have a data loading tool up to the task (read about it in the Loading Geolocation Data article) we’re going to be able to play with the awesome ip4r extension from RhodiumToad.

The name of the game is to put IP adresses on a map

In this article we are going to geolocalize our users given their IP address. That can be useful when you know the timezone settings of the different locations on earth that you have in the database, to automatically adapt to your user’s current location for example. Of course we’re going to do something more exciting than that. Read on!

Geolocation data loading

So the first step is to find an geolocation database, and several providers are offering that. The one I did choose for that example is the http://www.maxmind.com free database available at GeoLite Free Downloadable Databases.

After having had a look at the files in there, we define the table schema we want and load the archive, using the pgloader command we saw in our previous article Loading Geolocation Data:

$ ./pgloader.exe --quiet pgloader/test/archive.load
Now logging in '//tmp/pgloader//pgloader.log'.
Archive:  /Users/dim/Downloads/GeoLiteCity-latest.zip
  inflating: /private/var/folders/w7/9n8v8pw54t1gngfff0lj16040000gn/T/pgloader/GeoLiteCity-latest/GeoLiteCity_20130903/GeoLiteCity-Blocks.csv
  inflating: /private/var/folders/w7/9n8v8pw54t1gngfff0lj16040000gn/T/pgloader/GeoLiteCity-latest/GeoLiteCity_20130903/GeoLiteCity-Location.csv
                    table name       read   imported     errors       time
------------------------------  ---------  ---------  ---------  ---------
                       extract          0          0          0      0.925
                   before load          0          0          0      0.086
------------------------------  ---------  ---------  ---------  ---------
              geolite.location     438386     438386          0      8.841
                geolite.blocks    1790461    1790461          0     16.738
------------------------------  ---------  ---------  ---------  ---------
                       finally          0          0          0     32.646
------------------------------  ---------  ---------  ---------  ---------
             Total import time    2228847    2228847          0    59.236s

So we now have the following tables to play with:

> \dt+ geolite.
                    List of relations
 Schema  |   Name   | Type  | Owner | Size  | Description
 geolite | blocks   | table | dim   | 76 MB |
 geolite | location | table | dim   | 30 MB |
(2 rows)

> \d geolite.
    Table "geolite.blocks"
 Column  |  Type   | Modifiers
 iprange | ip4r    |
 locid   | integer |
    "blocks_ip4r_idx" gist (iprange)

     Table "geolite.location"
   Column   |  Type   | Modifiers
 locid      | integer | not null
 country    | text    |
 region     | text    |
 city       | text    |
 postalcode | text    |
 location   | point   |
 metrocode  | text    |
 areacode   | text    |
    "location_pkey" PRIMARY KEY, btree (locid)

Finding an IP address in our ranges

Here’s what the main data look like:

> table geolite.blocks limit 10;
        iprange        | locid
-----------------------+-------            |    17     |    49            | 14409            |    17            |    49           | 14614           | 47667           |   111 |   209          | 22537
(10 rows)

What we have here is a classic ip range column where we can see that the datatype output function is smart enough to display ranges either in their CIDR notation or in the more general start-end notation when no CIDR applies.

The ip4r extension provides several operators to work with the dataset we have, some of those operators are supported by the index we just created. And just for the fun of it here’s a catalog query to inquire about them:

> select amopopr::regoperator
    from pg_opclass c
         join pg_am am on am.oid = c.opcmethod
         join pg_amop amop on amop.amopfamily = c.opcfamily
   where opcintype = 'ip4r'::regtype and am.amname = 'gist';
(6 rows)

Note that we could have been using the psql \dx+ ip4r command instead of course, but that query directly list operators that the GiST index knows how to solve. The operator >>= reads as contains and is the one we’re going to use here.

> select *
    from geolite.blocks
   where iprange >>= '';

          iprange          | locid
---------------------------+------- |    75
(1 row)

Time: 1.220 ms

Geolocation meta-data

Now with the MaxMind schema that we are using in that example, the interesting data actually is to be found in the other table, the geolite.localtion one. Let’s use another IP address now, I’m told that google.us has address, where is that IP from:

> select *
   from      geolite.blocks
        join geolite.location using(locid)
  where iprange >>= '';
-[ RECORD 1 ]----------------------------
locid      | 2703
iprange    |
country    | US
region     | CA
city       | Mountain View
postalcode | 94043
location   | (-122.0574,37.4192)
metrocode  | 807
areacode   | 650

Time: 1.335 ms

Now you can actually draw that on a map as you have the location information as a point datatype containing both the longitude and latitude.

You might remember that we already saw how to use the earthdistance extension in our recent enouth article How far is the nearest pub? Time to try something more interesting then!

Emergency Pub

What if you want to make an application to help lost souls find the nearest pub from where they are currently? Now that you know their location from the IP address they are using in their browser, it should be easy enough right?

The pub names I got last time where all located in the UK, so we need an UK based IP address now: it seems that bbc.co.uk has address

> select *
    from      geolite.location l
         join geolite.blocks using(locid)
   where iprange >>= '';

-[ RECORD 1 ]---------------------------
locid      | 14023
country    | GB
region     | N7
city       | Tadworth
postalcode |
location   | (-0.2333,51.2833)
metrocode  |
areacode   |
iprange    |

What are the ten nearest pubs around if you’re just out of the BBC hosting services? Well, let’s figure that out before we get thirsty!

> with geoloc as
    select location
      from geolite.location l
           join geolite.blocks using(locid)
     where iprange >>= ''
    select name,
           round((pos <@> (select location from geoloc))::numeric, 3) as miles
      from pubnames
  order by pos <-> (select location from geoloc)
     limit 10;
          name          | miles
 Blue Anchor            | 0.299
 The Dukes Head         | 0.360
 The Blue Ball          | 0.337
 The Bell (aka The Rat) | 0.481
 Inn on the Green       | 0.602
 The Fox & Hounds       | 0.549
 The Chequers           | 0.712
 The Sportsman          | 1.377
 Kingswood Arms         | 1.205
 Tattenham Corner       | 2.007
(10 rows)

Time: 3.275 ms

For this query to be executed that fast, of course we had to create the right set of indexes. Here’s the explain plan we got:

QUERY PLAN
   CTE geoloc
     ->  Nested Loop
           ->  Bitmap Heap Scan on blocks
                 Recheck Cond: (iprange >>= ''::ip4r)
                 ->  Bitmap Index Scan on blocks_ip4r_idx
                       Index Cond: (iprange >>= ''::ip4r)
           ->  Index Scan using location_pkey on location l
                 Index Cond: (locid = blocks.locid)
   InitPlan 2 (returns $2)
     ->  CTE Scan on geoloc
   InitPlan 3 (returns $3)
     ->  CTE Scan on geoloc geoloc_1
   ->  Index Scan using pubnames_pos_idx on pubnames
         Order By: (pos <-> $3)
(15 rows)


While some geolocation data provider are giving you some libs and code to do quite fast lookups, any interesting thing you want to do with the geolocation data is about the meta data. And that’s where yet again PostgreSQL shines: you can actually use specialized data types and operators, JOINs and KNN searches, all from within a single query. You get back only those results you are interested into, and the application is then responsible for adding value to that, rather than processing the data itself.

Typically what the application here would be doing is drawing a map and locating the pubs on it, adding maybe descriptions and votes and notes on each address, maybe even the draft menu. An ideal application might even be able to join the draft menu of each nearby pub against your own preferences and offer you a nice short list ordered by what you’re most likely to want to drink at this hour.

Living in the future is both exciting and frightening!
